Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor

1 Satz/Sätze
MOQ
negotiable
Preis
Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Produktname: Schraubluftkompressor, Luftkompressormaschine
Name: Dieselschrauben-Luftkompressor
Leistung: 410 kW
Stromquelle: Diesel
Druck: 21-25bar/21-34bar
Luftverbrauch: 31-29 m2/min 36,5-32 m2/min
GESCHWINDIGKEIT: Bei der Prüfung der Leistungsfähigkeit des Fahrzeugs müssen die folgenden Bedingungen erfüllt sein:
Kraftstofftankkapazität: 700L
Schmieröl-Kapazität: 120 L
Kühlmethode: Luft/Wasserkühlung verfügbar
Anwendung: Bergbauprojekte, Kohle, Erz
Typ: Schraub
Kernkomponenten: SPS, Druckbehälter, Motor, Motor, Pumpe, Lager
Ausstattung: Stellfeste
Abmessungen: 4100*1800*2050 mm
Gewicht: 5600kg
Hervorheben:

Mining Screw Air Compressor 34bar

,

Mobile Screw Air Compressor

,

Screw Air Compressor Machine 25bar

Grundinformation
Herkunftsort: Zhejiang, China
Markenname: SANROCK
Zertifizierung: CE ISO 9001:2015
Modellnummer: Individualisiert
Zahlung und Versand AGB
Verpackung Informationen: Nacktes Paket für Maschinen, Holzkistenpaket für Ersatzteile, oder nach Kundenwunsch.
Lieferzeit: 18-25 Arbeitstage
Zahlungsbedingungen: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Versorgungsmaterial-Fähigkeit: 5000Sets/Sets pro Monat
Produkt-Beschreibung

Stationary Screw Air Compressor
A stationary screw air compressor is a robust, high-efficiency industrial air compression system designed for continuous operation in demanding environments. Utilizing dual rotary screw rotors, it delivers smooth, pulsation-free compressed air with energy efficiency and low maintenance requirements. The fixed installation ensures stability and noise reduction. Equipped with smart control systems, automatic drainage, and low-maintenance design, these compressors provide reliable performance in diverse environments.

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 0Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 1



Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 2

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 3

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 4Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 5



Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 6

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 7

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 8

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 7
Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 10

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 11

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 12Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 13

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 14Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 15

Company Profile

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 16

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 17

Mining Screw Air Compressor Machine Pressure 34bar 25bar Mobile High Pressure Screw Air Compressor 18

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
