Startseite /Produkte/Schraubluftkompressor/410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min

1 Satz/Sätze
MOQ
negotiable
Preis
410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Produktname: Schraubluftkompressor, Luftkompressormaschine
Name: Dieselschrauben-Luftkompressor
Leistung: 410 kW
Stromquelle: Diesel
Druck: 21-25bar/21-34bar
Luftverbrauch: 31-29 m2/min 36,5-32 m2/min
GESCHWINDIGKEIT: Bei der Prüfung der Leistungsfähigkeit des Fahrzeugs müssen die folgenden Bedingungen erfüllt sein:
Kraftstofftankkapazität: 700L
Schmieröl-Kapazität: 120 L
Kühlmethode: Luft/Wasserkühlung verfügbar
Anwendung: Bergbauprojekte, Kohle, Erz
Typ: Schraub
Kernkomponenten: SPS, Druckbehälter, Motor, Motor, Pumpe, Lager
Ausstattung: Stellfeste
Abmessungen: 4100*1800*2050 mm
Gewicht: 5600kg
Hervorheben:

Diesel Rotary Screw Air Compressor

,

410KW Rotary Screw Air Compressor

,

29m2/min Rotary Screw Air Compressor
Grundinformation
Herkunftsort: Zhejiang, China
Markenname: SANROCK
Zertifizierung: CE ISO 9001:2015
Modellnummer: Individualisiert
Zahlung und Versand AGB
Verpackung Informationen: Nacktes Paket für Maschinen, Holzkistenpaket für Ersatzteile, oder nach Kundenwunsch.
Lieferzeit: 18-25 Arbeitstage
Zahlungsbedingungen: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Versorgungsmaterial-Fähigkeit: 5000Sets/Sets pro Monat
Produkt-Beschreibung

screw air compressor used with water well drilling rig
This specialized rotary screw air compressor is engineered to deliver high-efficiency compressed air supply for water well drilling operations.
Featuring robust twin-screw technology, to power down-the-hole hammers and rotary drilling systems. superior cooling and lubrication for extended duty cycles in harsh drilling environments.
Integrated with vibration-resistant components and heavy-duty filtration systems, this compressor maintains high performance under dust and high-temperature conditions.
Automatic load/unload controls and energy-saving VFD options enhance fuel efficiency for mobile drilling rig configurations. With protection rating and corrosion-resistant coatings, it meets rigorous drilling industry standards for reliability in borewell construction and geothermal drilling applications.

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 0410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 1



410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 2



410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 3

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 4410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 5

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 6410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 7

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 8

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600


410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 9


410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 10

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 11

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 12410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 13

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 14410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 15

Company Profile

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 16

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 17

410KW Rotary Screw Air Compressor Diesel Power Source Air Consumption 31-29m2/min 18

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
