Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig

1Set/Sets pro Monat
MOQ
negotiable
Preis
Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Produktname: Bohrgerät
Name: FELSEN-ÖLPLATTFORM
Anwendung: Bergbauprojekt, Kohle, Erz, Wasserbrunnen
Besonderheit: Hydraulische Kontrolle, leichte Gewicht hohe Bohreffizienz
Bohrdurchmesser: 50-80mm
Bohrtiefe: 35 m
Shank -Modell: φ38mmx90mm
Garantie: 6 Monate
Schlagkraft: ≥225J
Aufprallfrequenz: ≥34Hz
Ausgangsdrehmoment der Bohrgestänge: ≥140NM
Arbeitbare Tunnelabmessungen: 2,2mx 2,2 m - 3,0 mx 3,0 m
Gesamtluftverbrauch: ≤ 225l/s
Bohrwinkel: 0-360 Grad
Kundendienst bereitgestellt: Online -Support, technische Support von Videos
Gewicht: 95 kg
Hervorheben:

Hydraulic DTH drilling machine 34HZ

,

Pneumatic borehole drilling rig

,

Surface drilling rig impact frequency
Grundinformation
Herkunftsort: Zhejiang, China
Markenname: SANROCK
Zertifizierung: CE ISO 9001:2015
Modellnummer: SR90
Zahlung und Versand AGB
Verpackung Informationen: Nacktpaket für Maschinen, Holzkastenpaket für Ersatzteile oder Kundennachfrage.
Lieferzeit: 15-25 Tage
Zahlungsbedingungen: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Versorgungsmaterial-Fähigkeit: 5000Set/Sets pro Monat
Produkt-Beschreibung

Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 0

Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 1
The sizes of different models of turntables are suitable for 2.2mx2.2m-2.7mx2.7m / 2.5mx2.5m-3.0mx3.0m

Tunnel Pneumatic DTH Drilling Rig This compact underground drilling machine is specifically engineered for

tunnel excavation and subterranean boring operations, utilizing compressed-air-powered DTH (Down-The-Hole)hammer technology for efficient rock fragmentation in confined spaces.

The rig features a low-profile design with 360° omnidirectional drilling capability, achieving precision boreholes

(Φ50-80mm) through granite and hard strata with minimal vibration transmission.

Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 2

Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 3Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 4Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 5

Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 6Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 7



Products Description

Type
Rotary Drilling Rig
Product name
Drilling Rig
Applicable
Building Energy ,Mining,borehole drilling rig
Parameters
Model SR90
Model SR150
Drilling Hole Diameter
50-80mm
80-140mm
Max. Drilling Hole Depth
35m
180m
Shank Model
φ38mmx90mm

Impact Force
≥225J
15000N
Impact Frequency
≥34HZ
60rpm
Output Torque of Drill Rod
≥140NM
1500-2000NM
Workable Tunnel Dimensions
2.2m x 2.2m - 3.0m x 3.0m
2.2m x 2.2m - 3.0m x 3.0m
Total Air Consumption
≤225L/s
120-350L/s
Drilling Angles
0-360 degrees
0-360 degrees
Mounted
No (Man Portable)
Two Wheels Trailer
Weight for Rocks Drilling Machine
95KG
450KG
Dimensions for Rocks Drilling Machine
890x360x305mm



Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 8Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 9

Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 10Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 11Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 12Hydraulic Pneumatic DTH Drilling Machine Impact Frequency 34HZ Surface Borehole Drilling Rig 13
